- 兩個完全并行的TCSPC FLIM通道
- 緊湊型BH?Simple-Tau或Power-Tau系統
- 兩個HPM-100-40 GaAsP混合型單光子探測器
- 可選：HPM-100-06混合型單光子探測器，IRF寬度<20 ps FWHM
- 可選：用于NIR FLIM的HPM-100-50混合探測器
- 可選：多波長?FLIM
- 出色的時間分辨率：IRF寬度6.5 ps FWHM
- 時間通道寬度低至813 fs
- 百萬像素FLIM，在256個時間通道上高達2048 x 2048像素
- 同時進行FLIM / PLIM
- 檢測波長范圍從360 nm到900 nm
- Ti：Sa激光器，OPO或bh ps二極管激光器激發
- 多光子FLIM和共聚焦FLIM的相同系統
- 探測器可以在NDD端口和共聚焦端口之間交換
- 系統是模塊化的：可以添加更多的FLIM通道
- Multiphoton FLIM
- Confocal FLIM
- Tuneable Excitation FLIM
- FLIM in 1 - 4 Fully Parallel Detection and Recording Channels
- Multi-Wavelength FLIM in 16 Wavelength Channels
- Multiphoton Multi-Spectral NDD FLIM
- FASTAC System Available
- Near-Infrared FLIM
- Time Series FLIM: Fast time Series or Microscope-Controlled Time Series
- Z Stack FLIM
- Spatial Mosaic FLIM
- Temporal Mosaic FLIM
- FLITS: Recording Transient Lifetime Effects in a Line Scan, Resolution Down to 1 ms
- PLIM (Phosphorescence Lifetime Imaging) Simultaneous with FLIM
- Fast Preview Mode
- Easy Switching Between Instrument Configurations and Operation Modes
- Runs at Any Scan Rate
- High Resolution Images, Up to 2048 x 2048 Pixels
- FCS and Cross-FCS, No afterpulsing Due to Use of Hybrid Detectors
